| Dimensions | Inches | Millimeters |
|---|---|---|
| Outer Lip Diameter | 1.63 | 41.4 |
| Mounting Stem I.D. | 0.31 | 7.9 |
| Overall Height | 0.81 | 20.6 |
| General Information | |||
|---|---|---|---|
| Material | See Below | ||
| Mounting Type | Snap Over | Cleats | Yes |
| Bellows | 0 | Suggested Use | Pick and Place |
| Style B Dimensions | Inches | Millimeters |
|---|---|---|
| Dimension A | 1.63 | 41.4 |
| Dimension B | 0.81 | 20.6 |
| Dimension C | 0.3 | 7.6 |
| Dimension D | 0.88 | 22.4 |
| Dimension E | 0.92 | 23.4 |
| Dimension E1 | 0.14 | 3.6 |
| Dimension F | 0.31 | 7.9 |
| Dimension H | 0.31 | 7.9 |
| Material | Working Temperature | Wear Resistance | Oil Resistance | Durometer |
|---|---|---|---|---|
| Vinyl | +32 - + 125 F | Excellent | Fair | A20 - A70 Range |
| FDA Vinyl | +32 - + 125 F | Excellent | Fair | A20 - A70 Range |
| Oil Resistant FDA Vinyl | +32 - + 125 F | Good | Excellent | A40 - A60 Range |
| Polyurethane | +32 - + 150 F | Good | Good | A20 - A70 Range |
| Silicone | -50 - + 400 F | Good | Good | A40 - A55 Range |
| FDA Silicone | -50 - + 400 F | Good | Good | A40 - A55 Range |
